Cast Iron Halifax Soil Branch Curve Double - 88 Degree x 100mm
| Code | HS4038 |
|---|---|
| EAN Code | 0691208229487 |
| Angle | 88 Degree |
| Brand | Hargreaves Halifax |
| Colour | Red Epoxy Coated |
| Material | Cast Iron |
| Style | Curve Double |
| Life Expected | 100 Years + |
| Specification | BS EN 877 |
| Size | 100mm |
Double branches in a soil stack have a number of uses, but essentially they are used for the purpose of connecting multiple pipe runs, usually in a vertical plane. They are most commonly seen on external elevations, connecting a number of rainwater or above ground drainage runs together into a single soil stack.
This 88 degree branch has a more swept design than the HS4034 branch, making it more suitable for foul rather than rainwater drainage.
As Halifax pipes and fittings have no sockets, couplers are required to connect this branch to a pipe.
A full dimensional drawing of this product can be found in the Halifax technical catalogue.
Cast Iron Halifax Soil
Halifax Soil is a socketless cast iron drainage system used for the above ground discharge of foul drainage and rainwater. An extremely flexible system, Halifax soil can be jointed using three different coupling options.
It is manufactured to BS EN 877 and is BBA approved. Correctly installed, Halifax soil can last over 100 years. It is exceptionally strong and is resistant to high temperatures, acids, alkalis and salt spray.
The Halifax cast iron soil system will not expand, contract, combust or emit toxic fumes. It is the ideal solution for rainwater and soil stacks in large public buildings or blocks of apartments.
