Drainage Junction Double Socket - 87.5 Degree x 110mm - Pack of 14
Click or tap the image to open in fullscreen
| Code | UT11090DPK14 |
|---|---|
| EAN Code | 5056919005433 |
| Weight (kg) | 7.504000 |
| Angle | 87.5 Degree |
| Brand | PBSL Group |
| Colour | Terracotta |
| Diameter | 110mm |
| Material | PVC-u |
| Pack Size | Pack of 14 |
| Style | Double Socket |
| Guarantee | 2 Year Manufacturer Guarantee |
| Specification | BS EN 1401-1 |
| System Size | 110mm |
This pack of 14 double socket 87.5 degree junctions is an economical bulk buy for 110mm underground drainage installations. Also known as branches, these fittings are used to bring a second pipe run into the main drain at right angles to the direction of flow.
Both ends of the main channel and the branch inlet are socketed to accept a length of 110mm drainage pipe. Any pipe that has been cut to length should be chamfered and lubricated with our SG100 lubricant before insertion into the socket to ensure the best possible seal. The sockets will also accept fittings with a pre-chamfered spigot end, such as single socket bends or gullies.
Buying 110mm drainage junctions by the pack lowers the cost per fitting and means spares are always available on site.
Please watch our overview video below
