FloPlast Drainage Bend Single Socket - 15 Degree x 110mm
In stock
Code
D167
Click or tap the image to open in fullscreen
| Code | D167 |
|---|
Product Overview
The FloPlast 110mm 15 degree bend with a single socket is designed for gentle alignment changes on underground runs. Often specified as a 15 degree drainage bend, it gives a smooth directional tweak without disrupting flow and integrates cleanly with standard 110mm underground systems.
Key Features
- Single socket 110mm bend with push-fit, ring-seal joint for a fast, reliable connection
- Accurate 15° geometry for slight changes of direction on straight runs
- Works neatly at chamber approaches and around branches or gullies
- uPVC construction, lightweight and durable, compatible with 110mm underground fittings
Installation Guidance
- Insert the spigot end into the receiving fitting following the line of flow
- If a pipe has been cut to length, chamfer the edge and apply SG100 lubricant before pushing into the socket to achieve a watertight seal
- For pipe lengths and additional fittings, browse our 110mm drainage pipe range
Alternative Options
- Need to fine-tune the angle on site? Use an adjustable bend that rotates from 0° to 90°
- For pipe-to-pipe connections on both sides, choose a matching 15 degree double socket bend
